Continuous inkjet printer for bottles

Price 165000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Continuous inkjet printer for bottles Specification

Type
QR Code Label Printer

Material
ABS Plastic, Metal

Capacity
2000 Labels/Day

Printing Speed
127 mm/sec

Computerized
Yes

Automatic Grade
Automatic

Plate Type
Flatbed Printer

Print Direction
Uni-directional/Bi-directional

Ink Type
Thermal Transfer/Direct Thermal

Color Management
Monochrome or Multi-color (Optional)

Control System
Microprocessor Controlled

Working Temperature
5C - 45C

Power
AC 220V, 50/60Hz

Size
Compact Desktop

Width
108 mm Print Width

Weight (kg)
3.5 kg

Dimension (L*W*H)
210 x 170 x 150 mm

Cutter
Auto/Manual (Optional)

Software Included
Label Design Software

Interface
USB, Serial, Ethernet

Media Type
Adhesive Labels, Paper Label Rolls, Synthetic Labels

Barcode Symbologies
1D & 2D Barcode including QR Code

Roll Diameter
Maximum 127 mm

Resolution
203 dpi

Display
LCD Display (Optional)

Ribbon Length
Up to 300 m

Sensor Type
Reflective/Transmissive

Supported OS
Windows, Linux

Noise Level
<60 dB

About Continuous inkjet printer for bottles

R5000 High-Performance Continuous Inkjet Printer

Precision. Power. Sustainability.

The R5000 Continuous Inkjet Printer is engineered for industries that demand uncompromising performance, reliability, and adaptability. Designed with cutting-edge technology, it ensures flawless printing across diverse materials while reducing operational costs and environmental impact.

Key Highlights

Dynamic Phase Adjustment Delivers unparalleled inkjet stability for consistent, high-quality prints.
Smart Operation Large 10.1-inch capacitive touch-screen with real-time print preview for effortless control.
Eco-Conscious Design Reduced solvent consumption supports sustainable, green production.
Rugged Reliability Enhanced sealing and IP65 protection ensure dependable performance in harsh environments.

Printing Capabilities

Print Head Duct: 3m | Nozzle: 60u
Printing Distance: 216mm | Height: 330mm
Lines: 15 | Counters: Up to 24
Speed: Up to 334m/min (5 dots in 1 line, 0.5 dot spacing)
Ink Options: High adhesion, food-grade, oil-resistant, dye inks with superior temperature resistance
Materials Supported: Carton, plastic, cable, metal, pipe, stone, glass, electronics, auto parts, chemical packaging, medical/food/gift boxes

Print Content & Codes

Content: Text, time/date, logos, shifts, serial numbers, barcodes, QR codes, dynamic databases
Barcode Types: CODE39, EAN13, CODE128, ITF-14, VIN, UPCA, and more
QR/2D Codes: QRcode, DataMatrix, PDF417, MicroQRcode, MICROPDF417

Machine Specifications

OS: Embedded Linux security system
Display: 10.1-inch capacitive touch (1280x800 resolution)
Interfaces: Photocell, encoder, alarm light, info control
Build: SUS 304 stainless steel | Weight: 18kg
Protection: IP65 | Certificates: CE, RoHS
Power: 100240V AC, 100W rated power
Environment: Operates reliably at 045C, 3070% RH
Memory: 256M

Why Choose the R5000?

High-Speed Industrial Printing Perfect for fast-paced production lines.
Versatile Material Compatibility From cartons to cables, metals to medical packaging.
Future-Ready Technology Dynamic data printing, database integration, and advanced barcode support.
Sustainability Built-In Lower solvent use, greener production, and long-term cost savings.
